ULTIRack+ Roof Rack

4 FreeLoad StopsSpecial Offer

Ships Direct From Van Guard Accessories - 3pm cut off - same day dispatch - (Mon-Fri)

Toyota ProAce 2016- L2H1 Twin Rear Doors - ULTI Rack+ Aluminium - 5 Bar Roof Rack

ULTIRack+ by Van Guard Accessories, a revolutionary van roof rack for professional work vans.

The ULTIRack+ is Van Guard Accessories latest design of roof rack, constructed from heavy duty aluminium & composites, offering a reduced fitted weight allowing for a higher payload to be carried.

As a gallery style roof rack the ULTIRack+ has evenly spaced cross bars & raised side rails making it well suited for roofing contractors, builders or trades people looking for a quiet, durable roof rack capable of carrying ladders, 8 x 4 sheets & building materials, the innovative T-Slot on every cross bar allows adjustable load stops, eyebolts and other accessories to be quickly installed & adjusted allowing multiple points to tie down. A full width stainless steel rear roller allows for simple loading and unloading without damaging the rear of your van.

The aerodynamic shape of ULTIRack+ cross bars & side rails drastically reduce wind noise & drag for a better driving experience when fitted.

Made To Last

The ULTIRack+ is manufactured from quality materials for a long lasting premium finish.

Side Rails: Aluminium | Anodised Finish

Crosstubes: Aluminium | Anodised Finish

Rear Roller: Stainless Steel

Connectors & Nose Cone: Durable Plastic | UV Protection

Safety First

Van Guard ULTIRack+ is 20g crash tested assuring you safe transportation of loads up-to 150 kg where applicable for the vehicle type.

20g Only

Fitting the ULTIRack+ by Van Guard Accessories

The ULTIRack+ is quick to install & comes complete with all necessary fixings &detailed fitting instructions, with simple step by step guidance to mount to the vehicles factory locations with no drilling required.

Tools required

Either

2 x 13mm spanners or sockets / ratchets

2 x 10mm spanner or socket / ratchet

1 x Narrow Spanner (supplied in the kit)

1 x T25 Torx bit (supplied in the kit)

1 Person Installation (2 Recommended for Larger Vans)

See the Optional Accessories for the Van Guard ULTIRack+ using the Accessories Tab Above

Pipe Carriers
Ladder Clamps
Ladder Slide & Secure
Eye Bolts (T-slot Mounted)
Additional Load Stops (T-slot Mounted)

Key Features

Heavy Duty & Lightweight
Aerodynamic Design
Anodised Aluminium & Composite Construction
Full Width Rear Roller Included
8 x 4 Capacity (Ideal for sheet materials)
T-Slot Cross Bars
4 Adjustable Load Stops Included
Fitting Instructions & All Fixings Included
Quick & Easy Installation
Designed & Made in Britian

Specification

MPNVGUR-272
To SuitToyota ProAce 2016- L2H1
Rear Door TypeTwin Rear
Fitted Weight (kg)26
Maximum Load (kg)150
ULTIRack+ Overall Width1491mm
ULTIRack+ Overall Length2800mm
Side rail height175mm
No Of Bars Included5 ULTI Rack Cross Bars+
Dimensions Cross Bars1354(L)60(W)30(D)
Bar T-Track Size21mm x 8mm
Height to underside of 1st bar84mm
Height to underside of 2nd bar74mm
Height to underside 3rd bar82mm
MaterialAluminium
ColourSilver
Fitting Time (Mins)45

Product questions

Product Questions

Q
What is the height of aluminium roof rack Kind regards.
A
Good morning Darren, Really sorry for delay, technical issue. with the website. Are you looking for the overall height? Is so: The height of a VGUR-072 from the roof at the middle fixing point to the top of the ULTI Rack side rail = Approximately 260mm.
